Auger Torque XHD1500 Trencher Only 1500mm Depth – 43-15S220040005001

Description

Auger Torque XHD1500 Trencher Only 1500mm Depth – 43-15S220040005001

The Auger Torque XHD Range of Trenchers is designed for Excavators between 5T-10T, High Flow Skid Steer Loaders and Backhoes.
With only the highest quality hydraulic motors and using Auger Torque’s own planetary gearbox, our trenchers have the reliability and power to ensure your trenching is carried out with ease. Chains are available in several different tooth configurations, whether you’re trenching in soft ground, mixed grounds or even permafrost allowing you to get the job done no matter what environment you are in. With the precision depth control skid the operator can accurately set the desired trench depth and be sure of accuracy for the entire length.

High Quality Motor and Gearbox
Using only the highest quality hydraulic motors that allow flow rates of up to 150LPM and then amplified by Auger Torque’s own bullet-proof planetary gearbox means that our trenchers have the reliability you need and the power to ensure your trenching is carried out with ease.

Epicyclic Gearbox
Torque is amplified by using the unique Auger Torque planetary gearbox. This system allows the motors output torque to be multiplied with extreme efficiency as well as ensuring the durability and reliability you need.

Hose and Adaptor Options
All Trenchers are supplied as standard with high quality hoses and adaptors.

Multiple Teeth Combinations
Chains are available in a number of different teeth configurations for trenching in soft ground, mixed grounds and even permafrost, allowing you to get the job done quickly.

Adjustable Depth Skid
A great feature that will make your job much easier is the precision depth control skid, which enables the operator to set the machine at up to three different trench depths.

Rapid Chain Adjustment
The length of the chain can be quickly adjusted with the removal of a screw to move the boom.

Specifications

• Suitable for – Excavators 5-10t and Skidsteer Loaders
• Oil Pressure Range – 180-240 Bar
• Oil Flow Range – 80-135lpm
• Unit Width – 1018mm
• Unit Height – 808mm
• Unit Length – 2562mm
• Cutting Width Range – 150-200mm

Warranty

• Lifetime Warranty against Shaft Dislodgement
• Planetary Gearbox Components – 72 months
• Hydraulic Motors – 36 months
• All other Products – 24 months
• All Other Parts / Products – 24 months

Options

• Skidsteer Loader Frame to suit XHD Range
  • Universal Side Shift Heavy Duty Frame
• Hitches to suit MT Trencher Range
  • 1.75 inch dia pin
  • 45mm dia pin
  • 50mm dia pin
  • 55mm dia pin
  • 60mm dia pin
  • 65mm dia pin
• 900mm Trenching Depth Chains to suit XHD900
  • 150mm wide – Earth
  • 150mm wide – Combination
  • 150mm wide – Tungsten
  • 200mm wide – Earth
  • 200mm wide – Combination
  • 200mm wide – Tungsten

All XHD Trenchers include Flat Face Couplers and Hydraulic Hoses. They are to Auger Torque standard and specification. Other specifications available on request.
