Muthing MU-M VARIO Flail Mower 3m 75 to 160hp – MU-M300

Description

Muthing MU-M VARIO Flail Mower 3m 75 to 160hp – MU-M300

A high standard for all farmers. Universally suited to any application area. MU-Vario® System as standard. Front and rear mounting as standard. Hydraulic side shift as standard. Crop discharge in front of the large support roller is also possible as standard. For example: For good germination of volunteer rape plants and when operating under difficult conditions. Long service life thanks to the internal Starinth® rear roller bearing system. Fast maintenance thanks to easily accessible and clearly marked lubrication points and automatic belt tensioning. Extremely narrow and exchangeable wearing skids ensure blockage-free operation and prevent crop accumulation.

Video – Muthing MU-M280 Vario Flail Mower Mulcher

Features:

• Manufactured from High-Quality QSt/E Steel with heavy-duty multi-position Headstock Cat. II for front and rear mounting.
• Hydraulic side shift: 56 cm lifting range (1 double-acting spool valve required).
• Gearbox with integrated over run clutch and through drive for 1000 r.p.m.
• Automatic belt tensioning.
• High tempered “M“ Hammer flails with self-sharpening cutting edge to ensure a clean cut and maximum shredding using less power.
• Spiral rotor with specially formed flail lugs to protect against damage from obstacles and internal bearings protecting against dirt, wear and tear.
• Large self-cleaning roller to carry the flail mower, adjustable for different heights.
• Wearing skids.
• Stand.
• P.T.O. shaft and guarding to ISO Standards.
• Optimised distance between the outer rotor circle and the roller guarantees perfect contour following and an even quality of cut.
• Purposely designed hood in conjunction with high rotor and cutting speeds and a fixed shredding bar spreads the shredded material evenly behind the roller giving an excellent Mulching and Shredding Quality.
• Patented removable shredding bar – System: “Shark Fin”.
• Vario Intake Bar.

Specifications:

• Working width: 300cm
• Overall width: 320cm
• Max Tractor HP (1000rpm): 150hp
• Weight: 1085kg
• Number of flails: 26

Options:

• Shock absorbing linkage springs (for Front Mounting recommended).
• Hydraulic Weight Transfer MU-SOFA®, for Front mounting recommended.
• Second patented removable shredding bar – System: “Shark Fin”.
• Hood Wear plate (delivery time to be asked for).
• Warning signs and lights (dealer fit).
• Galvanised frame for Warning signs and lights to be mounted on for Front and Rear Headstock Cat.II.
• Heavy P.T.O. shaft with cap bottom lubrication.
• Height adjustable rubber wheels with fixed axle.
• Working hours meter with electronic sensor.
• Alternative flails and rotor systems (3 back to back Flails, M Shackle Flails).
