Muthing MU-PRO VARIO Flail Mower 3.2m 95 to 220hp – MU-PRO320

Description

Muthing MU-PRO VARIO Flail Mower 3.2m 95 to 220hp – MU-PRO320

Maximum: Thoughput, Shredding, Performance. MU-Vario® System as standard. Front and rear mounting as standard. High quantities of biomass thanks to large MU-Vario® housing opening. Crop discharge in front of the large support roller is also possible as standard. Fast maintenance thanks to easily accessible and clearly marked lubrication points and automatic belt tensioning. Long service life thanks to the internal Starinth® rear roller bearing system. Extremely narrow and exchangeable wear runners ensure blockage-free operation and prevent crop accumulation.

Video – Muthing MU-PRO Vario Mulcher at Property in Macarthur NSW

Video – Muthing MU-PRO320

Features:

• Manufactured from High-Quality QSt/E Steel with multi-position headstock Cat. II + III for front and rear mounting.
• Hydraulic side shift: 56 cm lifting range (1 double-acting spool valve required).
• Heavy-duty gearbox with integrated over run clutch and through drive for 1000 rpm.
• Automatic belt tensioning.
• High tempered “M” Hammer flails to ensure a clean cut and maximum shredding using less power.
• Spiral Rotor with specially formed flail lugs to protect against damage from obstacles, bearings protected against dirt, wear and tear.
• Patented removable shredding bar – System: “Shark fin”.
• Large pivoting rear support roller for depositing mulch material either behind or in front of the roller, adjustable to different heights, with Roller Bearing Starinth.
• Side, wearing skids.
• Carbide wearing skids, removable.
• High tempered one-way spring steel protection flaps in front of the mower hood.
• Support leg.
• Slotted holes in the lower link receiver for perfect contour following and an even quality cut.
• Spreads the shredded material evenly behind the support roller.
• Excellent Mulching Quality.
• Heavy-duty PTO shaft with hardened inner pipe and cap bottom lubrication.
• Hood Liner, Vario Intake Bar and Roller Scraper Bar.

Specifications:

• Working width: 320cm
• Overall width: 340cm
• Max Tractor HP (1000rpm): 220hp
• Weight: 1500kg
• Number of flails: 28

Options:

• Front shock-absorbing spring assembly required.
• Alternatively, we recommend Hydraulic Weight Transfer MU-SOFA®.
• Alternative flails and rotor systems (triple Y-blades, “M”-Shackle flails).
• Adjustable cutting bar (Vario).
• Second patented removable shredding bar – System: “Shark fin”.
• Wear insert in housing (factory mounted).
• Cleaner cutting edge for displaced support roller.
• Refitting to an output speed of 750 rpm instead of 1000 rpm. (additional).
• Height adjustable support wheels, fixed axle with track 1.85 m, mounted at the 3-Point linkage.
• Warning signs with LED lighting equipment for front and rear mounting (5 m cable is included).
• Lighting equipment support bolted onto the 3-point trestle (factory mounted).
• Operating hours counter with sensor, time recording via angular momentum.
