Murray Series 08 Stump Jump Harrow System – 8102

Description

Murray Series 08 Stump Jump Harrow System – 8102

If your ground is uneven, roughly cleared or contains light stony areas then the flexible Murray series 08 Stump Jump Harrow is the secondary tillage implement to consider. Ruggedly constructed using High Carbon Steel, the floating stump jump action is a time tested agricultural implement. Suitable for breaking down clods, final seed preparation of ground and levelling pugged up or packed down heavy pasture country, Stump Jumps are also ideal for use in the preparation stage of vegetable growing and weed control.

Each Stump Jump section is attached to the drawbar by four hitching points one ahead of each row of tines, to ensure true tracking and correct stump-jump action.

Sets complete with drawbars range from coverage of 1.72mm (5ft 8in) to 8.63m (28ft 4in).

Available as a Lift Type set utilising our Series 21 Three Point Linkage Hoist Frame for ease of transportation. Set includes Front Lift Drawbar, Harrow sections, Rear Lift Drawbar including Lift Clips and Hoist Frame.

100% Australian made and owned.

Video – Why You Should Use Harrows on Your Farm

Specifications – Series 08 Stump Jump
Weight 41kg (90lb).
Coverage 0.86m (2ft 10in).
Tine spacing 44mm (1 3/4in).
Tine length 197mm (7 3/4in) approx.
Centre to centre of Front Hooks 222mm (8 3/4in).
5 Ranks / 20 Tines.

Features:
4 Point Pull (4PP). Cut Tine ends, pipe spacers throughout
section. Manufactured from 32 x 10mm carbon steel.

Model 8020: Section Only Price: $776.60

Drag Type Complete Sets with Standard (4 Point Pull) Drawbar:
8102 – 2 Section with bar 1.72m (5ft 8in): $2,033.90
8103 – 3 Section with bar 2.59m (8ft 6in): $3,096.50
8104 – 4 Section with bar 3.45m (11ft 4in): $4,176.70
8105 – 5 Section with bar 4.31m (14ft 2in): $5,383.40
8106 – 6 Section with bar 5.18m (17ft): $6,744.10

Drag Type Complete Sets with 2 pce bar and master bar:
8107 – 6 sections 5.18m (17ft): $7,086.20
8108 – 8 sections 6.90m (22ft 8in): $9,436.90
8110 – 10 sections 8.63m (28ft 4in): $12,070.30

Drawbar Only:
8021 – suits 2 sections 15kg – (5ft 8in)  : $480.70
8022 – suits 3 sections 23kg – (8ft 6in)  : $766.70
8023 – suits 4 sections 40kg – (11ft 4in) : $1,070.30
8024 – suits 5 sections 60kg – (14ft 2in) : $1,500.40
8025 – suits 6 sections 87kg – (17ft) : $2,084.50

Drawbar Only – 2 pce bars and master bar:
8026 – 79kg – (17ft) (suits 6 sections): $2,426.60
8027 – 132kg – (22ft 8in) (suits 8 sections): $3,224.10
8040 – 189kg – (28ft 4in) (suits 10 sections): $4,304.30

3-Point Linkage Hoist Lift Type Sets (4 Point Pull) Featuring Series 21 Hoist Frame:
8028 – 2 section 1.72m (5ft 8in) – 152kg: $3,562.90
8029 – 3 section 2.59m (8ft 6in) – 204kg: $4,776.20
8030 – 4 section 3.45m (11ft 4in) – 272kg: $6,012.60
8031 – 5 section 4.31m (14ft 2in) – 349kg: $7,361.20

Components Only:
21002 – Series 21 Hoist Frame only – 45kg: $1,123.10

Front Lift Drawbars Only (4PP)
8050 – suits 2 sections 1.72m (5ft 8in) – 15kg: $502.70
8048 – suits 3 sections 2.59m (8ft 6in) – 23kg: $790.90
8049 – suits 4 sections 3.45m (11ft 4in) – 40kg: $1,093.40
8068 – suits 5 sections 4.31m (14ft 2in) – 60kg: $1,524.60

Rear Lift Drawbars Only (incl Lift Clips)
8052 – suits 2 sections 1.72m (5ft 8in) – 10kg: $383.90
8033 – suits 3 sections 2.59m (8ft 6in) – 13kg: $532.40
8034 – suits 4 sections 3.45m (11ft 4in) – 23kg: $689.70
8069 – suits 5 sections 4.31m (14ft 2in) – 39kg: $830.50

Complete Set Comprises – Front Lift Drawbar, Harrow sections, Rear Lift Drawbar including Lift Clips and Series 21 3-Point Linkage Hoist Frame.

*Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!

Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.
