Silvan 1500L Trailed Supaflo Sprayer – DAB153AF8G

Description

Silvan 1500L Trailed Supaflo Sprayer – DAB153AF8G

Ideal for vineyards and orchards.

Model Specifications:

• Pump: Silvan oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body with brass heads and manifold. IDS1701:161L/min. capacity, 5000kPa pressure.
• Fan Size: 900mm axial flow type, 10 bladed fan with curved nylon reinforced blades, air straightening vanes and protective mesh cover. Powerhead (920mm) and Radak (1000mm) fitted with 10 bladed axial flow fan, centrifugal clutch and protective mesh cover.
• Nozzles: Flip-over type for dilute/concentrate spraying. Ceramic jets, stainless steel swirl-plates. 16 double sided nozzles (8 per side) twist on/off. The Powerhead has 24 double sided nozzles (12 per side) and the Radak ha 32 (16 per side).
• Gearbox: Two speed with neutral position, oil-bath type.
• Controls: 40 Bar electric section valves, master valve, electric pressure regulator and in-cab controls.
• Main Tank: Polytuff impact resistant polyethylene construction, calibrated sight line, flip to easy open lids. 40mm drain valve and built in chemical mixer. 40 Litre fresh water hand wash tank.
• Frame: Galvanised steel with jockey wheel and adjustable drawbar.
• Agitation: Pump bypass plus venturi agitator.
• Pressure Gauge: 100mm, 0-60 bar glycerine filled gauge.
• Filtration: Lid strainer, suction line strainer and stainless steel nozzle filters.
• Wheel Equipment: Glideflex suspension axle, 2 x 15inch tubeless tyres on painted rims (max speed rating 30km/hr).
• PTO Driveshaft: Quality Bondiolo and Pavesi constant velocity driveshaft with quick release pins and safety cover.
• HP Required: Minimum 60PTO HP.

Dimensions:

• Length: 3430mm – measured with drawbar in shortest position.
• Width: 1540mm
• Height: 1530mm
• Weight (DRY): 540kg

Options:

• Powerhead Conveyor (920mm Fan – in lieu of standard fan cowling).
• Radak Conveyor – Manual adjustment of top and bottom wings (1000mm fan – lieu of standard fan).
• Hydraulic kit for Radak Conveyor (top wings).
• Scram Jet (to suit Radak Conveyor).
• Leaf guard (to suit Powerhead and Radak).
• Twin nozzle (includes extra nozzles).
• Two-sided poly vineyard conveyor.
• Bravo 180S automatic rate controller.
• Flotation tyres – 400/60 x 15.5inch with fixed axle (in lieu of standard).

NOTE: Not all options will fit all models. Extra charges may apply to fitment of some options. Fitting of Powerhead and Radak includes upgrade to 920mm fan and uprated gearbox.
