Murray Series 03 Levelling Harrows – 5 Rank Deep Light Duty – 3701

Description

Murray Series 03 Levelling Harrows – 5 Rank Deep Light Duty – 3701

Murray Levelling Harrows are an excellent choice to complement sowing or cultivation implements. Designed to level soil and seedbeds, the flexible frame design provides durability in all soil types. 3 and 4 rank versions are suitable for use to cover seed in light to medium soils in conjunction with combines and seed drills. The 5 rank model is used in heavier soils to counter weed growth and break down large clods. It is a popular implement that complements cultivators, scarifiers or chisel plows.

If you require additional weight to work your land, a Heavy version of our Series 03 Levelling Harrows is available. Made from heavier High Carbon Steel, the Tine Spacing remains the same as the standard version.

The Series 03 Levelling Harrow is available in either 3 or 4 row widths allowing extensions in increments of 235mm (9 1/4in) to suit primary machines of almost any width. This allows a combination of harrow sections to be configured to suit your application.

A full range of standard and heavy duty drawbars are available to correctly match your soil conditions and available working width of your equipment. Harrow sets complete with drawbars range from 2.31m (7ft 7in) to 5.58m (18ft 4in) in width.

100% Australian made and owned.

Video – Why You Should Use Harrows on Your Farm

Specifications:
Tine Spacing 76mm (3in).
Tine Length 190mm (7 1/2in) approx.
Centre to centre of Front Hooks 235mm (9 1/4in).

Features:
High Carbon Cut Tines. Light models manufactured from 25 x 6mm carbon steel and Heavy models from 32 x 6mm.

Light Duty

Harrow Sections ONLY – 5 Rank Deep

15 Tine (3 x 5 Rank Deep) Coverage 0.7m (2ft 3 1/2in)
3024 (STD) Light 13kg (28lb): $325.60

20 Tine (4 x 5 Rank Deep) Coverage 0.93m (3ft 3/4in)
3025 (STD) Light 17kg (37lb): $426.80

Welded Non Standard
15 Tine (3 x 5 Rank Deep) Coverage 0.7m (2ft 3 1/2in)
3091 (Light): $355.30
3092 (Heavy): $462.00

20 Tine (4 x 5 Rank Deep) Coverage 0.93m (3ft 3/4in)
3093 (Light): $455.40
3094 (Heavy): $588.50

Complete Sets with Standard 5 Rank Harrow Sections and Standard Drawbar

Light Duty
3701 – 2.31m (7ft 7in) 2/15 Tine, 1/20 Tine – 50kg: $1,412.40
3702 – 2.56m (8ft 5in) 1/15 Tine, 2/20 Tine – 55kg: $1,541.10
3703 – 2.79m (9ft 2in) 4/15 Tine – 62kg: $1,690.70
3704 – 3.02m (9ft 11in) 3/15 Tine, 1/20 Tine – 67kg: $1,818.30
3705 – 3.25m (10ft 8in) 2/15 Tine, 2/20 Tine – 72kg: $1,941.50
3706 – 3.47m (11ft 5in) (16 Row) 1/15 Tine, 3/20 Tine – 77kg: $2,077.90
3707 – 3.70m (12ft 2in) 4/15 Tine, 1/20 Tine – 83kg: $2,266.00
3708 – 3.96m (13ft) 3/15 Tine, 2/20 Tine – 93kg: $2,398.00
3709 – 4.19m (13ft 9in) (20 Row) 2/15 Tine, 3/20 Tine – 98kg: $2,532.20
3710 – 4.41m (14ft 6in) 5/15 Tine, 1/20 Tine – 105kg: $2,704.90
3711 – 4.64m (15ft 3in) 4/15 Tine, 2/20 Tine – 110kg: $2,844.60
3712 – 4.87m (16ft) (24 Row) 3/15 Tine, 3/20 Tine – 115kg: $2,973.30
3713 – 5.13m (16ft 10in) 2/15 Tine, 4/20 Tine – 122kg: $3,207.60
3714 – 5.58m (18ft 4in) (28 Row) 6/20 Tine – 132kg: $3,435.30

Also Available in Heavy Duty

Harrow Sections ONLY – 5 Rank Deep

15 Tine (3 x 5 Rank Deep) Coverage 0.7m (2ft 3 1/2in)
3026 (STD) Heavy 16kg (35lb): $431.20

20 Tine (4 x 5 Rank Deep) Coverage 0.93m (3ft 3/4in)
3027 (STD) Heavy 23kg (51lb): $557.70

Welded Non Standard
15 Tine (3 x 5 Rank Deep) Coverage 0.7m (2ft 3 1/2in)
3092 (Heavy): $462.00

20 Tine (4 x 5 Rank Deep) Coverage 0.93m (3ft 3/4in)
3094 (Heavy): $588.50

Complete Sets with Standard 5 Rank Harrow Sections and Standard Drawbar

Heavy Duty
3801 – 2.31m (7ft 7in) 2/15 Tine, 1/20 Tine – 62kg: $1,754.50
3802 – 2.56m (8ft 5in) 1/15 Tine, 2/20 Tine – 70kg: $1,908.50
3803 – 2.79m (9ft 2in) 4/15 Tine – 74kg: $2,113.10
3804 – 3.02m (9ft 11in) 3/15 Tine, 1/20 Tine – 82kg: $2,266.00
3805 – 3.25m (10ft 8in) 2/15 Tine, 2/20 Tine – 90kg: $2,414.50
3806 – 3.47m (11ft 5in) (16 Row) 1/15 Tine, 3/20 Tine – 98kg: $2,576.20
3807 – 3.70m (12ft 2in) 4/15 Tine, 1/20 Tine – 101kg: $2,819.30
3808 – 3.96m (13ft) 3/15 Tine, 2/20 Tine – 114kg: $2,976.60
3809 – 4.19m (13ft 9in) (20 Row) 2/15 Tine, 3/20 Tine – 122kg: $3,136.10
3810 – 4.41m (14ft 6in) 5/15 Tine, 1/20 Tine – 126kg: $3,363.80
3811 – 4.64m (15ft 3in) 4/15 Tine, 2/20 Tine – 134kg: $3,528.80
3812 – 4.87m (16ft) (24 Row) 3/15 Tine, 3/20 Tine – 142kg: $3,682.80
3813 – 5.13m (16ft 10in) 2/15 Tine, 4/20 Tine – 152kg: $3,942.40
3814 – 5.58m (18ft 4in) (28 Row) 6/20 Tine – 168kg: $4,220.70

*Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!

Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.
