Murray Series 06 Spring Tine 3 Rank Harrow 1.83m - 6001

The Series 06 is a medium duty Spring Tine Harrow System popular with farmers for levelling operations in conjunction with primary and secondary tillage implements. Series 06 Harrows employ double spring tines available in Kinked or Straight Tines, both 10mm in diameter. The tine angle is adjustable to suit your field conditions.

Stock/Ref #: 6001 Brand: Murray

Can Transport Australia Wide!

Contact us today for sales or make enquiry below.

$1,597.20

Need Finance
For This Asset?

  • Fuss Free Finance
  • Quality Service
  • Tailored Finance Solutions

Description

Murray Series 06 Spring Tine Levelling Harrow Systems – 6001

The Series 06 is a medium duty Spring Tine Harrow System popular with farmers for levelling operations in conjunction with primary and secondary tillage implements. Series 06 Harrows employ double spring tines available in Kinked or Straight Tines, both 10mm in diameter. The tine angle is adjustable to suit your field conditions.

Model – 6001 – 1.83m (6′)

This is a 3 rank model – Tine spacing is 75mm (3in)
Tine diameter is 10mm, Kinked (standard) or Straight Tine (Optional)
Tine Length 450mm (17 3/4in) approx
Rank Spacing 235mm (9 1/4in) STD 3 Rank
1 Mount Arm per unit

Series 06 Spring Tine Levelling Harrows Features

3 rank versions are available in three sizes ranging from 1.37m (4ft 6in) to 2.28m (7ft 6in). Murrays also manufacture an extra wide 14in (335mm) Rank Spacing Straight Tine units which seeks to provide superior trash flow handling capabilities.

Manual lifting has been eliminated with harrows able to be folded and travel with the principal implement.

100% Australian made and owned.

Specifications:
Tine Spacing for 3 Rank models 75mm (3in)
Tine Diameter 10mm Kinked or Straight Tine (optional)
Tine Length 450mm (17 3/4in) approx
Rank Spacing 235mm (9 1/4in) STD 3 Rank
1 Mount Arm per unit except for 2.28 (7ft 6in) units which have 2 Mount Arms per unit.

Features:
Kinked design Tines as standard. – Straight design Tines optional. This Harrow is designed to fit on to the rearbar of scarifiers, chisel plows, cultivators etc. Adjustable Tine angle.

Series 06 Spring Tine Harrow Systems Medium Duty 3 Rank
Kinked Tines (STD) and 9 1/4in (235mm) Rank Spacing

3 Rank Models Complete Unit – Kinked
6002 1.37m (4ft 6in) – 64.5kg: $1,376.10
6001 1.83m (6ft) – 77.5kg: $1,597.20
6015 2.28m (7ft 6in) 2 arms – 121 kg: $2,594.90

3 Rank Models Tine Section Only – Kinked
6008 1.37m (4ft 6in) – 37kg: $871.20
6003 1.83m (6ft) – 50kg: $1092.30
6014 2.28m (7ft 6in) 2 arms – 66kg: $1585.10

Series 06 Spring Tine Harrow Systems Medium Duty 3 Rank
Straight Tines (Optional) and 9 1/4in (235mm) Rank Spacing.

3 Rank Models Complete Unit – Straight
6023 1.37m (4ft 6in) – 64.5kg: $1,376.10
6024 1.83m (6ft) – 77.5kg: $1,597.20
6025 2.28m (7ft 6in) 2 arms – 121 kg: $2,594.90

3 Rank Models Tine Section Only – Straight
6027 1.37m (4ft 6in) – 37kg: $871.20
6028 1.83m (6ft) – 50kg: $1092.30
6029 2.28m (7ft 6in) 2 arms – 66kg: $1,585.10

Mount Arm Options

6004 Standard Mount Arm to suit 75mm to 100mm (3in to 4in) square frames positioned on the flat. Supplied with complete Units as standard unless another type of Mount Arm is specified. 27.5kg: $504.90
6047 Mount Arm to suit a 75mm (3in) square frame positioned on the edge. 29.5kg: $603.90
6051 Mount Arm to suit the centre frame of an Alfarm A530 cultivator. 75mm (3in) across 150mm (6in) down. 29.5kg: $556.60
6055 Mount Arm to suit some Gason applications. 100mm (4in) across 150mm (6in) down. 29.5kg: $556.60

*Murray Harrows must be pulled (towed) by a tractor correctly fitted with an approved rollover protection structure. Murray Harrows are NOT intended for use with an ATV or Ride On Lawn Mower.

All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!

Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.
