Silvan Cane Boom Linkage Sprayers 600L – BP130/20 Pump with 4 Row Cane Boom – K06N-125C with 035-4NL
Model Specifications K06N-125C – Linkage Sprayer:
- Pump: Silvan self-priming oil-backed diaphragm type with nitrile diaphragms and corrosion resistant, cast anodised aluminium body. BP130/20: 132 L/min. capacity 2000kPa pressure.
- Nozzles: 2 x twin nozzle bodies per spray head and air induction nozzles.
- Controls: 4 outlet single lever control valve with pressure regulation and gauge.
- Tank: Low profile 600ltr Polytuff impact resistant polyethylene construction, external sightline with floating ball and non-spill offset screw-down lid with single breather. 15L freshwater tank with screw-down lid and on/off tap. 4L toolbox with polythylene lid.
- Frame: Fully galvanized steel, cat II adjustable hitch.
- Agitation: Bypass agitation.
- Pressure Gauge: 0-25 Bar dual stage glycerine filled gauge.
- Filtration: Lid strainer and suction line strainer with stop valve fitted at side of tank to enable ease of filter maintenance.
- PTO Driveshaft: Quality driveshaft with quick release pins & safety cover.
Model Specifications 035-4NL – 4 Row Cane Boom (Spider)
- Fully galvanised construction, to suit row widths from 1.5-1.8m with 500-1300mm ‘spider’ spray head.
- Spray heads have heavy duty hinges to withstand drag, parallelogram tracking system.
Dimensions without Boom:
- Trailed/Linked: Linkage
- Tank Size: 600.00 litres
- Pump Size: 58 L/min
- Length: 1025mm
- Width: 1150mm
- Height: 1300mm
- Product Weight: 105kg
Cane boom 4 row or 6 row. Fully galvanized construction, to suit row widths from 1.5 – 1.8m with 500-1300mm shield spray head and brush skirts or ‘spider’ spray head. Spray heads have heavy duty hinges to withstand drag, parallelogram tracking system.
- 4 Row Cane Boom (Spider) – 035-4NL.
- 4 Row Cane Boom (Shielded) – 035-4N.
- 6 Row Cane Boom (Spider) – 035-6NL.
- 6 Row Cane Boom (Shielded) – 035-6N.
- Broadacre boom attachment (to suit 4 row) – 035-4B.
- Broadacre boom attachment (to suit 6 row) – 035-6B.
- Hydraulic lift, galvanized single hydraulic system – 032-40DL.
- 70L flush tank kit to flush the filter, spraylines and nozzles – K99-47.
- Electric control 3 section with in cab pressure adjustment – K99-29.
- Electric control 4 section with in cab pressure adjustment – K99-49.
- Electric control 5 section with in cab pressure adjustment – K99-50.
- Bravo 180S automatic rate controller – J99-151.
- Silmix chemical hopper – K99-21.
Note: $550 charge applies for Dealer fitment.
All prices include GST. Please allow extra for freight.
Delivery is available Australia Wide.
Dealer enquiries welcome.
Finance is now available!
Contact Farm Supplies today for sale or more information!
Photos are for illustration only, and actual product may vary from those shown.
Prices are correct at time of posting the ad, but are still subject to change.
E & OE.
