Wiedenmann Terra Spike SL6 Aerators – 8700040

Description

Wiedenmann Terra Spike SL6 Aerators – 8700040

The Wiedenmann TERRA SPIKE® SL6 is a compact, high-performance deep aeration machine, purpose-built for golf greens, tees, and sand-based sports fields. Designed to remove soil
compaction up to 21cm depth, it provides precise, high-quality turf care while maintaining smooth gameplay.

Deep Aeration Efficiency: The Terra Spike SL6 penetrates soil to a depth of 21 cm, alleviating compaction and promoting healthy root growth, improved water infiltration, and better nutrient absorption.
Compact and High-Coverage Design: Lightweight and easily mounted on tractors from 25HP, the machine offers excellent area coverage without compromising work quality. At 55 mm hole spacing, it achieves up to 2,240 m²/h at a maximum speed of 1.6 km/h.
Quick and Precise Adjustments: The central tool-free adjustment system, combined with an adjustment crank and QuickFit mechanism, allows rapid and accurate setting of working depth and loosening angle.
Exchangeable Tine Holders: Tool heads can be swapped quickly and easily with a single screw, enabling fast transitions between applications for spiking, aeration, and dethatching.
Operator Safety and Comfort: Equipped with a rear roller and Vibra-Stop, the machine minimises vibration and protects the operator during use, enhancing comfort during long operating periods.

Specifications:

• Overall Width – 1.16m
• Working Width – 1.4m
• Weight – 470kg
• Tractor HP (min) – 25

Standard Build Inclusions:

• Drive Type (must select one)
  • 1237022 Drive 280 RPM
  • 1237023 Drive 360 RPM
  • 1237024 Drive 485 RPM
• 1500120 Set of 12 Solid Tines 12 mm x 200 mm

Optional Extras:

• 1237680 Set of Turf Retainers for 4 Tines/Tine Holder (55 mm)
• 1237026 Core Swath Board
• 1237975 Nail Board for 5 × 135 mm / 8 × 150 mm Needle Tines (6 Required)
• 1237970 Multi-Tine Holder for 6 Tines – 12 mm Mounting Diameter (6 Required; Max Working Depth 200 mm; Use Only with 280 or 360 rpm Drive)
• 1237973 Multi-Tine Holder for 8 Tines – 8 mm Mounting Diameter (6 Required)
• 1237950 Slitting knives 130 mm (80 pcs.): 1 set for 150 mm spacing or 2 sets for 75 mm spacing
• 1236660 Tine Holder for 4 × 12 mm Tines – 1 Set Included with Base Machine
• 1237960 Tine Holder for Top-Eject Tines (6 Required)
• 1237920 Lower Link Extension
• 1196890 Soil Probe – 1000 mm Length
• 1196895 Soil Probe – 650 mm Length
• 8709001 Buffer Kit (Replace After 3 Years/100 Operating Hours)
• 8709600 Additional Year Warranty Extension (24 Months Total)
